Graphtec FC2250-120VC Large Format Flatbed Cutting Plotter

The Graphtec FC2250-120VC is a high-precision, large-format flatbed cutting plotter designed for professional cutting, marking, and creasing applications. Featuring a generous 1200 × 920 mm (47.2 × 36.0 inch) effective cutting area, a dual-head tool configuration, and vacuum media hold-down, it delivers reliable performance for packaging prototypes, industrial films, garment patterns, stencils, and a wide range of specialty materials.

With a maximum cutting force of 9.8 N (1 kgf / 1000 gf), the FC2250-120VC supports demanding production workflows that require precision, repeatability, and flexible material handling.

Key Features

• Large Cutting Area: 1200 × 920 mm (47.2 × 36.0 inches) for large-format materials and production layouts.
• Dual-Head Tool Configuration: Supports Tool 1 with up to 4.9 N (500 gf) and Tool 2 with up to 9.8 N (1000 gf) of force.
• Vacuum Media Hold-Down: Helps keep compatible materials securely positioned during cutting and marking.
• High-Speed Cutting: Maximum cutting speed of 400 mm/s (16 inches/s).
• Precision Control: Mechanical resolution of 0.0025 mm (2.5 μm).
• ARMS Registration System: Advanced Registration Mark Sensing System supports registration-based workflows.
• Reverse-Side Processing: Supports reverse-side cutting and creasing with ARMS.
• Multiple Tool Support: Compatible with cutter blades, marking pens, and creasing/scoring tools.
• Repeat and Copy Functions: Helps streamline repetitive cutting and production tasks.
• Flexible Connectivity: Includes USB 2.0 Full Speed and RS-232C interfaces.

Technical Specifications

Compatible Media

The FC2250-120VC can process a wide range of materials, subject to material thickness, rigidity, tool selection, and cutting conditions.

• Marking films, including vinyl, fluorescent, and reflective films
• Stiff paper and card for stencils, up to 1.0 mm thick
• Polystyrene foam sheets
• Sandblast rubber sheets, up to 1.0 mm thick
• Microflute board, including F and G grades
• Clear plastic sheets for box and packaging applications
• High-intensity reflective film
• Selected PET films for industrial and electronic applications
• Chipboard, magnetic sheets, matte board, and gasket materials, where compatible with the selected tool and setup

Supported Tools and Functions

• Cutter Blade: Supersteel cutter blade for compatible cutting applications.
• Marking Pens: Water-based fiber-tip pens and oil-based ballpoint pens.
• Creasing and Scoring: Supports creasing/scoring tools for suitable materials.
• Registration: ARMS registration mark sensing for supported workflows.
• Production Functions: Copy, repeated cutting, and reverse-side cutting and creasing with ARMS.

Software and Connectivity

• D-Cut software support for importing DXF data.
• Cutting Master plug-in for Adobe Illustrator, subject to compatible software versions.
• GP-GL and HP-GL command emulation.
• USB 2.0 Full Speed and RS-232C connectivity.

Compatible Operating Systems

• Windows 10, Windows 8.1, Windows 8, Windows 7, and Windows Vista
• Mac OS X 10.6–10.10

Compatibility note: These are legacy operating systems listed in the supplied specifications. Driver availability and compatibility with newer Windows or macOS versions should be confirmed before purchase or installation.

Power and Operating Environment

Physical Specifications

Applications and Industries

• Garment and apparel pattern cutting and marking
• Shoe pattern cutting and marking
• Packaging design and prototype development
• Industrial films for electronics
• Monument and stone sandblast mask production
• Reflective highway and road signs
• Offset printing blanket cutting
• Architectural model building
• Stencil, gasket, and sandblast rubber template production
• Corrugated cardboard and short-run packaging samples

Optional Accessories and Considerations

• An optional 3 mm blade is listed for thicker compatible materials, including materials up to E-flute corrugated board, subject to setup and material requirements.
• An optional creasing tool is available for suitable corrugated media.
• Tooling, software, and accessories may be optional and are not necessarily included with the standard machine.
• Maximum cutting performance depends on the material, thickness, tool, blade condition, and operating settings.

Certifications

Listed certifications and compliance markings include UL, cUL, CE marking, FCC-A, EN55022-A, and RoHS. Confirm the specific certification documentation for the machine and market of sale.

Product Summary

The Graphtec FC2250-120VC is a versatile flatbed cutting plotter for businesses that need accurate, repeatable processing across a broad range of compatible materials. Its 1200 × 920 mm cutting area, vacuum media hold-down, dual-tool configuration, and registration functions make it suitable for packaging prototypes, apparel patterns, industrial films, stencils, and other professional cutting applications.
