Graphtec FC2250-60VC Flatbed Cutting Plotter

The Graphtec FC2250-60VC is a professional large-format flatbed cutting plotter designed for precision cutting, marking, and creasing across a wide range of industrial and commercial materials. With a 610 × 920 mm effective cutting area and a dual-tool configuration, it provides flexible processing capabilities for packaging prototypes, apparel patterns, industrial films, signage, stencils, and other specialized applications.

The FC2250 series features a digital servo system, high mechanical resolution, and adjustable cutting pressure. The FC2250-60VC model uses a vacuum suction system to help hold compatible media securely on the table during processing. Its two-tool design supports different pressure requirements, with a maximum force of 4.9 N (500 gf) for Tool 1 and 9.8 N (1 kgf) for Tool 2.

Key Features

• Large-format flatbed design: Effective cutting area of 610 × 920 mm (24 × 36 in).
• High cutting force: Dual-tool configuration with up to 500 gf on Tool 1 and 1,000 gf on Tool 2.
• Vacuum media hold-down: Helps secure compatible materials during cutting and marking.
• Precision processing: Mechanical resolution of 0.0025 mm (2.5 μm).
• Flexible tool support: Supports compatible supersteel blades, plotting pens, and creasing or scoring tools.
• Versatile media compatibility: Designed for marking films, stiff paper and card, foam sheets, sandblast rubber, microflute board, and other supported materials.
• ARMS registration system: Supports registration-mark workflows, including reverse-side cutting and creasing.
• Productivity functions: Includes copy, creasing, and repeated-cut functions.
• Standard connectivity: RS-232C and USB 2.0 Full Speed interfaces.

Technical Specifications

Compatible Materials

The FC2250-60VC is designed to process a broad selection of materials used in graphics, packaging, and industrial production, including:

• Marking films, including vinyl, fluorescent, and reflective films
• Stiff paper and card for stencils, up to 1.0 mm thick
• Polystyrene foam sheets, subject to material specifications
• Sandblast rubber sheets up to 1.0 mm thick
• Microflute board, F and G grades
• Clear sheets used for plastic boxes
• High-intensity reflective film, with the required blade and backing configuration
• Apparel patterns and pattern-making materials
• Packaging samples and suitable corrugated board
• Gasket and stencil materials compatible with the selected tooling

Material note: Maximum thickness and compatibility vary by material type. Confirm the manufacturer's material guidelines and test the selected blade, pressure, and hold-down method before production.

Tools and Processing Functions

Connectivity and Operating Systems

Operating system note: The listed operating systems are legacy versions. Verify current driver availability and compatibility with your computer, operating system, and cutting software before purchasing.

Power and Operating Environment

Physical Specifications

Industries and Applications

• Garment pattern cutting and marking
• Shoe pattern cutting and marking
• Packaging design and prototype production
• Monument and stone sandblast mask production
• Industrial films for electronics
• Reflective highway and road sign production
• Offset printing blanket cutting
• Architectural model building
• Gasket and stencil production
• Short-run packaging and corrugated board prototypes

Important Notes

• The FC2250 series is available with different table sizes and media hold-down systems. This description covers the FC2250-60VC configuration.
• The FC2250-60VC uses vacuum suction. Confirm the required vacuum system and compatible accessories for the intended application.
• Some FC2250 configurations support inclined operation, while vacuum-table configurations are specified for horizontal operation. Verify the exact model configuration before installation.
• The source lists an optional 3 mm blade for thicker materials up to E-flute and an optional creasing tool for corrugated media. Confirm availability and compatibility before ordering.
• Material thickness limits, cutting results, and repeatability depend on material properties, tool selection, and operating conditions.
• Verify current driver and software compatibility before connecting the plotter to a modern computer.

Product Summary: The Graphtec FC2250-60VC is a precision flatbed cutting plotter for businesses that require versatile processing of sheet materials. Its 610 × 920 mm working area, vacuum media hold-down, dual-tool design, and 1,000 gf maximum tool force make it suitable for packaging prototypes, apparel patterns, industrial films, stencils, and other compatible production applications.
