Graphtec FC4510-60

Graphtec FC4510-60 Flatbed Cutting Plotter

The Graphtec FC4510-60 is a professional flatbed cutting plotter designed for sign-making, packaging, and industrial applications. Featuring a large 860 × 600 mm effective cutting area and a maximum cutting speed of 750 mm/s, it delivers efficient and precise processing for a wide variety of compatible sheet materials.

Built around a digital servo system, the FC4510-60 supports contour cutting, half cutting, perforated cutting, plotting, and creasing applications. Its flatbed configuration helps hold materials in position during processing, making it a practical solution for businesses that work with materials that are difficult to feed through conventional roll-fed cutting plotters.

Key Features

• Large cutting area: Effective processing area of 860 × 600 mm (33.8 × 23.6 in).
• High-speed performance: Maximum cutting speed of 750 mm/s (30 in/s).
• Digital servo system: Designed for controlled, accurate cutting and plotting operations.
• Flatbed media handling: Uses an adhesive sheet or mat to hold compatible materials in place.
• Two-tool configuration: Supports cutting and plotting tools, with up to 600 gf cutting pressure for both tools.
• Fine mechanical resolution: 0.005 mm (5 μm) mechanical resolution.
• Versatile processing: Supports contour cutting, half cuts, perforated cuts, plotting, and creasing workflows.
• Standard connectivity: RS-232C and USB 2.0 High Speed interfaces.
• Space-efficient design: Flatbed construction suitable for professional production environments.

Technical Specifications

Compatible Materials

The FC4510-60 supports a range of materials for graphics production, packaging prototypes, and selected industrial applications, including:

• Marking films, including vinyl, fluorescent, and reflective films
• Stiff paper and card for stencil production, up to 0.5 mm thick
• Polystyrene foam sheets up to 0.8 mm thick
• Sandblast rubber sheets up to 1.0 mm thick
• Microflute board, F and G grades
• Clear sheets used for plastic boxes
• High-intensity reflective film, subject to the appropriate blade and backing requirements

Material note: Compatibility and maximum thickness depend on the material's properties, tool selection, and operating conditions. Confirm suitability before production.

Tools and Processing Functions

Connectivity and Operating Systems

Operating system note: The listed operating systems are legacy versions. Verify current driver availability and compatibility with your computer, operating system, and cutting software before purchasing.

Power and Operating Environment

Physical Specifications

Recommended Applications

• Professional sign-making and vinyl graphics
• Packaging design and prototype production
• Stencil cutting
• Paper and card processing
• Creasing and scoring for folding applications
• Reflective graphics and marking films
• Plastic sheet processing for compatible materials
• Sandblasting mask production
• Contour cutting and reverse-side processing with supported workflows

Important Notes

• Material thickness limits depend on the material type and operating conditions. Confirm suitability and test settings before production.
• Cutting accuracy and repeatability depend on the media, tool setup, and specified operating conditions.
• Verify current driver and software compatibility before connecting the plotter to a modern computer.
• Confirm the required adhesive sheet or mat and compatible tools for your intended materials and workflow.

Product Summary: The Graphtec FC4510-60 is a professional flatbed cutting plotter offering a generous 860 × 600 mm working area, cutting speeds up to 750 mm/s, and precise digital servo control. It is suited to sign shops, print businesses, packaging designers, and industrial users who need accurate processing of compatible sheet materials.
