HP Designjet T520 24 inch Color Inkjet ePrinter

Product Description

PRODUCT HIGHLIGHTS

- Print Resolution: 1200dpi
- Print Speed: 275 Sq. Feet;/Hour
- Ethernet & Wi-Fi Connectivity
- Output 24.0" Wide Sheets & Rolls
- Roll Feed With Automatic Cutter
- Print On Heavy Media Up To 280gsm
- Internal Memory: 1.0GB

Printing Method

Printing Technology4-color thermal inkjet

Maximum Resolution1200 x 1200 input dpi

Line Accuracy±0.1%

Ink PaletteCyan, Magenta, Yellow, Black

Ink TypeDye-Based: Cyan, Magenta, Yellow
Pigment-Based: Black

Ink Cartridge Configuration4 individual cartridges

Maximum Optical Density2.10 maximum black optical density (8 L*min)

Printer LanguageHP-GL/2, HP-RTL, HP PCL 3 GUI, JPEG, CALS G4

Print SpeedUS D - Best: 16.3 min/page
US D - Normal: 9.3 min/page
US D - Draft: 1.3 min/page

Paper Handling

Paper-Feed MethodSheet feed, roll feed, input tray;

CutterAutomatic cutter

Maximum Paper Width24.0" (60.96 cm)

Paper SizesSheet: 8.3 x 11.0 to 24.0 x 66.0" (21.0 x 27.94 to 60.96 x 167.6 cm)
Roll Width: 11.0 to 24.0" (27.94 to 60.96 cm)

Paper TypesPlain: Bond, coated, heavyweight coated, recycled, plain, bright white
Technical: Natural tracing, vellum
Film: Clear, matte
Photo: Satin, gloss, semigloss, premium, polypropylene
Self-Adhesive: Adhesive, polypropylene

Media ThicknessUp to 11.8 mil (299.72 micron)

Media WeightRoll Feed: 60 to 280 g/m2
Manual Feed: 60 to 280 g/m2
Input Tray: 60 to 220 g/m2

Maximum Roll Print Length150.0' (46.0 m)

Maximum Media Roll Diameter3.9" (9.91 cm)

Connectivity

InterfaceHi-Speed USB 2.0
Fast Ethernet (100Base-T)
Wi-Fi

OS CompatibilityWindows: Windows 7 Ultimate/Professional/Home Premium, Vista Ultimate/Business/Home Premium, XP (32/64-bit) Professional/Home, Server 2008 (32/64-bit), Server 2008 R2, Server 2003 (32/64-bit)
Mac: OS X 10.6, 10.7, 10.8
Citrix: XenApp, XenServer

Internal Memory1.0 GB

Physical

Control PanelLCD: 4.3" color touchscreen
Icons: Wireless, Home, Help, Previous/Next, Back, Cancel

Power Requirements100 to 240 V AC ±10%, 50/60 Hz, 1200 mA max

Power ConsumptionPrinting: < 35 W
Power Save: < 4.5 W
Standby: < 0.3 W

Acoustic NoiseSound Power (Operating): 6.5 B(A)
Sound Power (Standby): < 3.4 B(A)
Sound Pressure (Operating): 48 dB(A)
Sound Pressure (Standby:) < 16 dB(A)

CertificationsSafety: CSA, EU (LVD and EN 60950-1 compliant), Russia (GOST), Singapore (PSB), China (CCC), Mexico (NYCE)
Electromagnetic: Class B requirements, including USA (FCC rules), Canada (ICES), EU (EMC/R&TTE Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Certified as Class A product: Korea (KCC)
Environmental: Energy Star, WEEE, EU RoHS, REACH, EuP, FEMP

Temperature / HumidityOperating Temperature: 41 to 104 °F (5 to 40 °C)
Recommended: 59 to 95 °F (15 to 35 °C)
Storage Temperature: -13 to 131 °F (-25 to 55 °C)
Operating Humidity: 20 to 80%
Storage Humidity: 0 to 95%

Dimensions (WxDxH)38.9 x 20.9 x 11.2" (98.81 x 53.09 x 28.45 cm)

Weight56.2 lb (25.49 kg)

Packaging Info

Package Weight107.5 lb

Box Dimensions (LxWxH)

43.5 x 24.0 x 23.0"
