Ricoh Gen5 / 7PL-35PL Printhead (Two Color, Long Cable)

Product Description

Ricoh Gen5 / 7PL-35PL Printhead, 50cm Long with The Head, 39cm Long for The Cable (Two Color, Long Cable)

This GEN5 UV printhead is suitable for a range of UV and Solvent printers. It supports up to four colours and has a total of 1.280 nozzles. It is built with longevity and robustness in mind and used in the latest industrial inkjet printers. This is Ricoh original printhead part (number MH5420) and it is covered by a manufacturer warranty.

Product Specifications

- Dimensions: 89 x 25 x 69 mm (excluding cables)
- Head materials: SST, Nickel alloy and Epoxy Adhesive
- Nozzle plate surface: Coated SST
- Number of nozzles: 4 x 320 nozzles
- Nozzle spacing: 0.1693 mm
- Nozzle density: up to 600 npi
- Piezo type: D33 Stacked PZT
- Temperature control: Integrated Heater and Thermistor
- Operator temperature range: Up to 80° C
- Native drop volume: 7 pl
- Drop volume range: 7 – 35 pl
- Drop velocity: 7 m/s
- Jetting frequency: Up to 60 kHZ
- Ink compatibility: UV Inks
- Life: 100 billion actuations per nozzle

To be used with:

A-Starjet

- 5.0

- 5.0 L

Agfa

- Jeti Mira MG2716 S/HS
- Jeti Mira MG2732 S/HS

- Jeti Tauro H2500
- Jeti Titan HS

- Jeti Titan S

Akad

- NovaJet UV M6

AmicaSystems

- FG2512

AOjet

- APro 250FR

CET Color

- Q5-1000
- Q5-1000h

- Q5-250
- Q5-250h

- Q5-500
- Q5-500h

Docan

- 1212 UV
- FR3210

- FRT3116
- M10

- M6
- M8

Flora

- LJ180G
- LJ320G

- PP 3220UV
- PP1612UV-G

- PP2512UV-G

Handtop

- HT1600UV HR4
- HT1610UV FR4
- HT2500UV HR8

- HT2512UV-D FR8
- HT3116UV FR8
- HT3200UV HG12

- HT3200UV HR8

Indask

- F1212 UV
- F2030 UV

- F2518 UV
- FR2510 UV

- FRT3215 UV
- FRT3225

LavaPrint

- 4896-HRC

- 78118-HRC

Mantis

- MTS-UV1513RI

Mehta

- POWER 4S

- POWER PRO 3200

Mimaki

- JV400-130SUV

- JV400-160SUV

Mtutech

- MT-RH1510R

TitanJet

- 3302-G5N

TwinJet

- MC – F2030G

- MC – F2513G

Vivex

- CS 3300MC

Remarks: Original
The Total Length of this printhead is 500mm including cables. (Manual measurement, there may be 1cm error of physical)
