ROLAND DE-3

Product Description

Desktop Rotary Engraver

Work table size : 305 x 230 mm

XYZ Axis Drive System: Stepper motor; 3-axis simultaneous control

Software resolution : 0.01 mm/step

Maximum Material Thickness: 40 mm (38 mm when using the nose cone)

Unit Utama

Power Supply

AC 100V–240V ± 10%, 50/60Hz

Others

- XYZ Axis Drive System: Stepper motor, 3-axis simultaneous control
- Operating Speed: 0.1 ~ 60 mm/sec (XY axis) & 0.1 ~ 30mm/sec. (Z axis)
- Software Resolution: 0.004" (0.01 mm)/step
- Mechanical Resolution: 0.00125 mm/step (XYZ-axis)
- Spindle Motor: Brushless DC Motor
- Spindle Speed: 5.000 ~ 20.000 rpm
- Tool Loading: Cutter Holder, Collet Type
- Maximum Material Thickness: 40 mm (38 mm when using the nose cone)
- Connection: USB, Ethernet (10 BASE-T/100 BASE-TX)

Dimensions

616 x 587 x 390 mm (WxDxH)

Engraving Size

305 x 230 mm
