Graphtec FC2250-120MG Large Format Flatbed Cutting Plotter

The Graphtec FC2250-120MG is a precision flatbed cutting plotter designed for professional cutting, marking, and creasing applications across a wide range of materials. Featuring a 1200 × 920 mm (47.2 × 36.0 inch) effective cutting area, a dual-tool configuration, and a magnetic media hold-down system, it supports versatile production workflows in packaging, industrial manufacturing, garment pattern development, signage, and specialty material processing.

With a maximum cutting force of 9.8 N (1 kgf / 1000 gf), the FC2250-120MG combines precision motion control with flexible material handling. Its magnetic hold-down configuration is designed for compatible magnetic workholding setups, while its tiltable table supports horizontal or inclined operation.

Key Features

• Large Cutting Area: 1200 × 920 mm (47.2 × 36.0 inches) for larger patterns, layouts, and production materials.
• Dual-Tool Configuration: Tool 1 supports up to 4.9 N (500 gf), while Tool 2 supports up to 9.8 N (1000 gf).
• Magnetic Media Hold-Down: Designed for compatible magnetic workholding applications.
• Horizontal or Inclined Operation: The MG model's table configuration supports horizontal and inclined operation.
• High-Speed Cutting: Maximum cutting speed of 400 mm/s (16 inches/s).
• High Mechanical Resolution: 0.0025 mm (2.5 μm) mechanical resolution.
• ARMS Registration System: Advanced Registration Mark Sensing System supports registration-based workflows.
• Reverse-Side Processing: Supports reverse-side cutting and creasing with ARMS.
• Multiple Tool Support: Compatible with cutter blades, marking pens, and creasing/scoring tools.
• Production Functions: Includes copy, repeated-cutting, and creasing functions.
• Flexible Connectivity: RS-232C and USB 2.0 Full Speed interfaces.

Technical Specifications

Compatible Media

The FC2250-120MG supports a broad range of materials, subject to material thickness, tool selection, and workholding requirements.

• Marking films, including vinyl, fluorescent, and reflective films
• Stiff paper and card for stencils, up to 1.0 mm thick
• Polystyrene foam sheets
• Sandblast rubber sheets, up to 1.0 mm thick
• Microflute board, including F and G grades
• Clear plastic sheets for packaging and box applications
• High-intensity reflective film
• Selected PET films for industrial and electronic applications
• Chipboard, magnetic sheets or rolls, matte board, and gasket materials, where compatible with the selected tooling and setup

Supported Tools and Functions

• Supersteel Cutter Blade: For compatible cutting applications.
• Marking Pens: Water-based fiber-tip pens and oil-based ballpoint pens.
• Creasing and Scoring Tool: For suitable folding and scoring applications.
• ARMS Registration: Supports registration-mark sensing workflows.
• Reverse-Side Processing: Reverse-side cutting and creasing with ARMS.
• Repeat Production: Copy and repeated-cutting functions for recurring jobs.

Software and Connectivity

• D-Cut software support for importing DXF data.
• Cutting Master plug-in for Adobe Illustrator, subject to software-version compatibility.
• GP-GL and HP-GL command emulation.
• USB 2.0 Full Speed and RS-232C connectivity.

Compatible Operating Systems

• Windows 10, Windows 8.1, Windows 8, Windows 7, and Windows Vista
• Mac OS X 10.6–10.10

Compatibility note: These are legacy operating systems listed in the supplied specifications. Confirm driver availability and compatibility with newer Windows or macOS versions before purchase or installation.

Power and Operating Environment

Physical Specifications

Applications and Industries

• Garment and apparel pattern cutting and marking
• Shoe pattern cutting and marking
• Packaging design and prototype development
• Industrial films for electronics
• Monument and stone sandblast mask production
• Reflective highway and road signs
• Offset printing blanket cutting
• Architectural model building
• Stencil, gasket, and sandblast rubber template production
• Corrugated cardboard and short-run packaging samples

Optional Accessories and Considerations

• An optional 3 mm blade is listed for thicker compatible materials, including materials up to E-flute corrugated board, subject to material and setup requirements.
• An optional creasing tool is available for suitable corrugated media.
• Software, blades, tools, and accessories may be optional and are not necessarily included with the standard machine.
• Magnetic workholding requires compatible materials or fixtures. Confirm that your intended media and workflow are suitable for the FC2250-120MG configuration.
• Actual cutting performance depends on the material, thickness, tool, blade condition, and operating settings.

Certifications

Listed certifications and compliance markings include UL, cUL, CE marking, FCC-A, EN55022-A, and RoHS. Confirm the specific certification documentation for the machine and market of sale.

Product Summary

The Graphtec FC2250-120MG is a versatile large-format flatbed cutting plotter for professional applications requiring precision cutting, marking, and creasing. Its 1200 × 920 mm work area, magnetic hold-down system, dual-tool configuration, and tiltable table design make it a flexible solution for compatible materials used in packaging, signage, garment patterns, industrial films, and model making.
